Connection Server II

DESCRIPTION

• The connection server is providing a communication environment between iNELS BUS System with the third party devices, for which their protocols are also translated and submitted.
• The iNELS application's environment enables us to control all these technologies from just one app.
• If the connection server is present in the installation, then it enables option for controlling the installation by application - lighting, blinds, heating, etc., also IP cameras, intercom, air conditioning.
• It also allows the communication with the domestic voice intercom 2N. It can also arrange the information from the weather station Giom or data from energy meters (electricity, water, gas), which is visualized in clear graphs.
• The device connection server uses the Rock Pi hardware and the apps requires a license relative to the MAC address of the device.
• While connecting with the devices connection server, it‘s recommended to use an uninterruptible power supply (UPS), which ensures that, there will be no power outage.
• As a part of the package, we also included an SD card where we previously installed Linux OS on it and its needed software equipment.
• The confi guratution is happening on its own web interface, where the default IP address is not fi xed. (The IP address is assigned from the DHCP server and it‘s needed to be known when we‘re connected to the network).

TECHNICAL PARAMETERS

• Power: USB Type-C PD 2.0 with 9V/2A, 12V/2A, 15V/2A , 20V/2A
• Video Output: HDMI
• Audio Output: 3.5mm jack with mic
• Processor (CPU): 64bits hexa core processor, Dual Cortex-72, frequency 1.8GHz with qual Cortex-A53, frequency 1.4GHz
• Memory (SDRAM): 4 GB
• Communication Interface: Gigabit Ethernet, dual-band 802.11ac WiFi 5, Bluetooth 5.0
• Connecting peripherals: 2x USB 3.0 , 2x USB 2.0
• Dimensions: 92,9 x 65 x 50,6 mm (l,w,h)
